Non-contact surface temperature measurement
-
Button-activated laser pointer for accurate targeting
-
Selectable emissivity values—choose from 7 preset material options, set a custom emissivity value, or adjust to a known temperature
-
Statistics Scan mode—continually displays/updates average, standard deviation, min/max surface temperature and number of readings while measuring one reading per second
-
Certificate of Calibration showing traceability to NIST included (Long Form)
-
5.7:1 distance to spot ratio—ideal for measuring large areas
-
Smart Trend indicators identify rising, falling or stable readings
Features
-
Surface temperature is constantly updated and displayed simultaneously
-
Button-activated laser pointer for simple, accurate targeting
-
NEW Larger 2.8'' impact resistant color touchscreen with redesigned keypad for quick menu navigation
-
NEW On-gage help explains menu items at the touch of a button
-
RESET feature instantly restores factory settings
-
NEW Weatherproof, dustproof, and water-resistant—IP65-rated enclosure
-
NEW Ergonomic design with durable rubberized grip
-
Non-contact sensor won't get caught or worn
-
Shock-absorbing, protective rubber holster for added impact resistance
-
Two year warranty on gage body AND probe
-
Certificate of Calibration showing traceability to NIST included (Long Form)
-
Fast response precision sensor provides accurate, repeatable readings
-
5.7:1 distance to spot ratio—ideal for measuring large areas
-
Smart Trend™ indicators identify rising, falling, or stable readings
-
PosiTector body accepts all PosiTector IRT, DPM, 6000, 200, RTR, SPG, SST, SHD, and UTG probes easily converting from a infrared thermometer, to a dew point meter, coating thickness gage, surface profile gage, soluble salt tester, Shore hardness durometer or ultrasonic wall thickness gage
-
Selectable emissivity values - choose from 7 preset material options, set a custom emissivity value, or adjust to a known temperature
-
NEW Auto rotating display with Flip Lock
-
Scanning Statistics Scan Mode—continually displays/updates average, standard deviation, min/max surface temperature, and number of readings while measuring one reading per second
-
NEW Screen Capture—save 100 screen images for record keeping and review
-
Pause function allows readings to be manually recorded
-
HiLo alarm audibly and visibly alerts when readings exceed user-specified limits
-
NEW Instant-on feature quickly powers up the gage if recently powered down
-
NEW Up to 30% longer battery life
-
USB Port for fast, simple connection to a PC and to supply continuous power. USB cable included
-
PosiSoft USB Drive—stored readings and graphs can be accessed using universal PC/Mac web browsers or file explorers. No software required.
-
Every stored measurement is date and time stamped
-
Software Updates via web keep your gage current
-
Includes PosiSoft suite of software for viewing, analyzing & reporting data
Specifications
Range
Accuracy
Resolution
Temperature Range
-70° to 380° C
±1° C + 1%*
0.1° C
-94° to 716° F
0.1° F
±1.8° F + 1%*
Laser Pointer
Class 2 < 1mW
Distance to Spot Ratio (D:S)
5.7:1
Emissivity
Adjustable
Response Time
< 500 μs (95% response)
Spectral Response
2 – 14 μm
Includes ALL features as shown on left plus...
-
NEW Storage of 1,000 readings per probe—stored readings can be viewed or downloaded
Includes ALL features as shown on left plus...
-
NEW Storage of 250,000 readings from multiple probes in up to 1,000 batches
-
Trend Charts graph readings in real-time
-
NEW Touchscreen keyboard for quickly renaming batches, adding notes, and more
-
WiFi technology wirelessly synchronizes with PosiSoft.net and downloads software updates
-
Bluetooth 4.0 Technology for data transfer to a mobile device running the PosiTector App or optional portable printer. BLE API available for integration into third-party software.
-
Integrate with third-party software, drones, ROVs, PLCs, and robotic devices using several industry-standard communication protocols
-
Store thickness, profile, environmental salt contamination, hardness, and wall thickness measurements in individual batches
All gages come complete with IR temperature probe, protective rubber holster, wrist strap, 3 AAA batteries, instructions, nylon carrying case with shoulder strap, protective lens shield, Long Form Certificate of Calibration traceable to NIST, USB cable, two year warranty.
SIZE*: 127 x 66 x 25.4 mm (5'' x 2.6'' x 1'')
WEIGHT*: 137 g (4.9 oz.) without batteries
*Size and weight are for the PosiTector gage body only and do not include the probe.
Download PosiTector® IRT Infrared Thermometer Full Catalog
