| Description | Parameter |
| Resolution (Route Area/Pitch | 16 x 32 Pixels (Route) 73 Model |
| Resolution (Destination Area)/Pitch |
16 x 64 Pixels (Destination) 73 Model |
|
Pitch |
12.5mmX 10mm(Route) 12.5mm x 10mm(Destination) |
| Display Area | 165 x 1610 (mm) |
| L.E.D color (Route Area) | Red |
| L.E.D color (Destination Area) | Amber |
| L.E.D Brightness | Min1500 up to 2500mcd/pixel |
| L.E.D Type | Oval |
| L.E.D Module Type | 16 x 32 & 16 x 48 with black sunshade |
| View Distance/Angle of reflection | 60mtrs / 70-110⁰ |
| Operating Voltage Range (DC) | 24(16 -32vdc) |
| Power (Watt) | <65 Watt |
| Brightness Control Level | Adjust brightness automatically |
| Function | Route (Static) & Destination (Static & Scrolling) Two layers wording |
| Input data format (RS485) | Dot Matrix (RS485) |
| Over Current Protection | Build in system |
| Lifespan (hours) | 100,000 MTBF (Mean time between failure) |
| Possibility to deferent animations | Scrolling, Going up, Fixed, Blinking and Falling |
| Operating Temperature | (00C to 800C) |
