Technical Specifications | |
Input |
4 HDMI (Female HDMI); 4 VGA (Female 15 pin HD); 1 YPbPr, 2 C-video (Female RCA); 1 S-video (4 pin mini DIN connector); 0.5V~2.0Vp-p; 75Ω |
Video Input Signal | HDMI, VGA, YPbPr & C-video |
Video Output |
1 HDMI (Female HDMI); 1 VGA (Female 15 pin HD); 1 HDBaseT (RJ45 connector); 0.5V~2.0Vp-p; 75Ω |
Video Output Signal | DMI, RGBHV & HDBaseT |
Audio Input |
6 Stereo Audio (RCA female connector for YPbPr, C-video & S-video; 3.5mm jack for VGA ); 4 HDMI audio (embeded digital audio); 2 MIC (3P captive screw connector);>10kΩ |
Audio Output |
Stereo line audio (RCA connector); 50Ω 2x10W@8Ω/ 2x20W@4Ω amplifier (5P captive screw connector); |
Resolution |
1920x1080; HD 1360x768; 1280x720; WXGA 1280x800; XGA 1024x768 |
Input |
3 Stereo Audio for line audio, 2 digital embeded audio |
Bandwidth |
HDMI: 6.75Gbps; C-video/S-video: 150MHz; YPbPr: 170MHz; VGA: 375MHz |
Maximum Pixel Clock | 145MHz |
Control | Buttons, IR & RS232 |
Power Supply | 100VAC ~ 240VAC, 50/60Hz; 65W |
Control / Remote | IR remote, Buttons & RS-232 |
Temperature | -20 ~ +70ºC |
Humidity | 10% ~ 90% |
Chassis Dimension | W483xH44xD235mm |
