Length : 1000 - 6000 mm
Belt Width : 150 - 600 mm
Belt Type : 2 mm x 2 ply PVC belt
Structure : Aluminium
Speed : 2 - 12 mtr/min
Max. Load : 70 kg
Aluminium Side Frame with E.G. Slider Bed
Single phase variable speed motor
Light, portable and flexible
Easy to maintain
Wide range of belt width and length
| MODEL | CONVEYOR LENGTH (MM) | BELT WIDTH (MM) | FRAME WIDTH (MM) | MOTOR (W) | POWER SUPPLY | GEAR HEAD RATIO | BELT SPEED (M/MIN) | MAX. LOAD CAPACITY INCLINED ANGLE | ||
| 0 | 10 | 15 | ||||||||
| MH15 | 1000 - 6000 | 150 | 220 |
60 90 |
220V AC 50 HZ 1 PHASE 220V AC 50 HZ 1 PHASE |
18 18 |
2 TO 12 0.5 TO 8 |
35 50 |
20 30 |
15 24 |
Malaysia
