| GENERAL | |
| Warm up time |
When enabled : 30 seconds or less (23 degrees Celsius room temperature) When disabled : 24 seconds or less (23 degrees Celsius room temperature) |
| First output speed | 3.6 sec (A4 LEF) |
| Continuous output speed | A4 LEF : 55/45 ppm |
| A3 : 27/22 ppm | |
| Memory | 4GB |
| HDD: 128GB | |
| Dimensions (W x D x H) |
4 Tray Model : W 620 x D 723 x H 880 mm Tandem Tray Model : W 620 x D 723 x H 1141 mm |
| Weight | 4 Tray Model : 97kg |
| Tandem Tray Model : 133 kg | |
| COPIER | |
| Multiple copy | Up to 999 |
| Resolution | 600 dpi |
| Zoom | From 25 to 400% (in 1% steps) |
| PRINTER | |
| Printer language | Standard: PCL5/ PCL6 |
| Option | Adobe® PostScript® 3™ |
| Printing Resolution |
PCL Driver : Standard: 1200dpi x 2400dpi, High Quality : 1200 x 2400 dpi, High Resolution : 1200 x 1200 dpi Adobe PostScript 3 Driver : High Speed (Standard): 600 x 600dpi, High Quality : 1200 x 2400 dpi, High Resolution : 1200 x 1200dpi |
| Interface | Standard: Ethernet 1000 BASE-T/100BASE-TX/10BASE-T, USB3.0 |
| Option: Wireless LAN (IEEE 802.11a/b/g/n/ac) | |
| Operating System |
Standard [PCL Driver] Windows® 10 (32bit/64bit), Windows 8.1(32bit/64bit) Windows ® Server® 2019 (64bit), Windows® Server® 2016(64bit), Windows® Server® 2012 R2 (64bit), Windows® Server® 2012 (64bit), [Mac OS X Driver] Mac OS X 10.15/10.14/10.13/10.12, OS X 10.11 Optional [Adobe® PostScript® 3™ Driver] [PCL Driver] Windows® 10 (32bit/64bit), Windows 8.1(32bit/64bit) Windows ® Server® 2019 (64bit), Windows® Server® 2016(64bit), Windows® Server® 2012 R2 (64bit), Windows® Server® 2012 (64bit), [Mac OS X Driver] Mac OS X 10.15/10.14/10.13/10.12, OS X 10.11 |
| SCANNER | |
| Scan speed | 55/45 ppm |
| Resolution | 600 x 600 dpi, 400 x 400 dpi, 300 x 300 dpi, 200 x 200 dpi |
| FAX (OPTION) | |
| Circuit |
Telephone subscriber line, PBX, Fax communication (PSTN), maximum 3 ports *3 (G3-3 ports) |
| Transmission Mode | ITU-T G3 |
| Original Size | Max : A3, 11” x 17”, Long document (Longest 600mm) |
| Recording Paper Size | Max : A3, 11” x 17”; Min : A5 |
| Transmission speed | 2 seconds and more but fewer than 3 seconds |
| PAPER HANDLING | |
| Recommended paper size |
Maximum: SRA3 (320 x 450mm), 12” x 18” (305 x 457mm), A3 [12” x 19” (305 x 483mm), 320 x 483mm when using Bypass Tray] Minimum: A5 Postcard (100 x 148 mm) [89 x 98mm when using Bypass Tray] |
| Paper input capacity |
Standard : Tandem Tray Model : 500 sheets x 2 Tray + 810 sheets + 1175 sheets + Bypass Tray 90 sheets Optional : 4 Tray Module : 500 sheets x 2 tray Tandem Tray Module : 810 sheets + 1175 sheets HCF B1 : 2030 sheets Maximum: 4 Tray Model : 5105 sheets (Standard + Tandem Tray Module + HCF B1) Tandem Tray Model : 5105 sheets (Standard + HCF B1) |
| Paper output capacity | Upper Center : 250 sheets (A4 LEF), Lower Center : 250 sheets (A4 LEF) |
| Paper weight |
Paper tray(s): 52 - 300 gsm Bypass tray: 52 - 300 gsm |
| ECOLOGY | |
| Power consumption |
2.2 kW (AC220V ±10%) 2.4 kW (AC240V ±10%) Sleep mode: 0.5 W (AC230V) Ready Mode: 89 W (AC230V) |
| Power Supply | AC220-240 V±10%, 10A, 50/60 Hz common |
|
For availability of models, optional apparatus and software, please contact Mewamax Sdn Bhd. All brand and/or product names are trademarks of their respective owners. Specifications are subject to change without prior notice. |
|
