Specifications
- Porting Size: 1 1/2"
- Capacity: 0 to 122 gpm (462 lpm)
- Air Distribution Valve: No-lube, no-stall design
- Solids Handling: Up to 6.3mm
- Heads up to: 125 psi or 289 ft. of water (8.6 bar or 88 meters)
- Stroke: 0.37 gallons (1.7 liters)
- Max Operating Pressure: 125 psi (8.6 bar)
- Country of Origin: USA
Penerangan
Sandpiper HDB1½ & HDB40 Metallic Heavy Duty Ball-Valve AODD Pump
The SANDPIPER HDB1½ AND HDB40 METALLIC 1½" (40 MM) is designed to excel in the most challenging pumping conditions. Built with SANDPIPER’s advanced engineering in mind, this compact 1½” SANDPIPER heavy-duty ball valve pump combines high efficiency with rugged durability, handling abrasive slurries and harsh fluids with ease.
Key Features of HDB 1 1/2 & HDB40 AODD Pump
- Side-Ported Option: Provides flexibility for confined spaces by positioning ports at the center of the pump, optimizing installation and fluid solution.
- Extended Wear protection: Equipped with extended-wear packages for longer service life in abrasive-slurry applications.
- Heavy-Duty Construction: Includes thicker castings and weighted check valve balls for consistent performance even under severe conditions.
- Evolution performance enhancements: Improved flow capacity with reduced air/gas consumption, delivering optimized efficiency without compromising on durability.
Applications
- Abrasive Slurry handling: With robust wear pads and heavy-duty bushings, ideal for high-abrasion environments.
- Confined Space Installations: Side-ported design enables easy setup in restricted areas, optimizing operational flexibility.
- Chemical processing: Compatibility with various chemicals, ideal for handling aggressive and hazardous fluids safety.
Why Choose SANDPIPER Heavy-Duty Air Operated Double Diaphragm Pump
- ESADS+: Reduces downtime by up to 90%, allowing main air and pilot valve access without removing the pump.
- Extended Component Durability: Plunger bushings, actuator pins, and wear-resistant diaphragms ensure reliability in high-stress applications.
- Guaranteed performance: Backed by a 5-year limited warranty and SANDPIPER’s anti-stamm air valve guarantee.
FOR MORE INFORMATION, CLICK HERE:
HDB1½ and HDB40 Metallic 1½" (40 mm) AODD Heavy-Duty Ball Valve Pump
