Diaphragm Pumps
HDB2 and HDB50 Metallic 2" (50 mm) AODD  Heavy-Duty Ball Valve Pump
HDB2 and HDB50 Metallic 2" (50 mm) AODD  Heavy-Duty Ball Valve Pump

 2

HDB2 and HDB50 Metallic 2" (50 mm) AODD  Heavy-Duty Ball Valve Pump

ABS Engineering & Trading Sdn Bhd flag
Kategori: Diaphragm Pumps Tersedia
Boleh Dibeli di Laman Web Rasmi
Untuk maklumat lanjut, lawati laman web rasmi kami di absfluidsolution.com
Lawati Laman Web Rasmi Hubungi kami
Specifications
  • Porting Size: 2" NPT 2" BSP
  • Capacity: 0 - 135 gpm (511 lpm)
  • Air Distribution Valve: No-lube, no-stall design
  • Solids Handling: Up to 0.375" (9mm)
  • Heads up to: 125 psi or 289 ft of water (8.6 bar or 88 meters)
  • Stroke: 0.46 gallons (8.6 bar)
  • Max Operating Pressure: 125 psi (8.6 bar)
  • Weight: Top Ported Aluminum 88 lbs (40 kg) Top Ported Cast Iron 166 lbs (75 kg) Top Ported Stainless Steel 179 lbs (81 kg) Bottom Ported Aluminum 95 lbs (43kg) Bottom Ported Cast Iron 172 lbs (78 kg) Bottom Ported Stainless Steel 186 lbs (84 kg)
Penerangan

HDB2 and HDB50 Metallic AODD heavy-duty ball valve pumps, available in 2-inch (50 mm) sizes for industrial applications in challenging environments.HDB2 and HDB50 Metallic 2" (50 mm) AODD – Heavy-Duty Ball Valve Pump

Stands out for its capability to move both thin and highly viscous fluids, including those laden with small solids, under extreme conditions. Available in top- and down-poting configurations, this robust pump delivers exceptional durability and versatility across challenging environments, effectively handling abrasive slurries and solid-laden fluids.





HDB2 And HDB50 Features



Applications
  • Top-port option: Ideal for fluids with floating solids, suspended particles, or entrained gases, ensuring smooth discharge flow and reducing build up.
  • Down-Port option: Optimized for setting solids, with discharge below the center to allow solids to settle in the elbow, minimizing diaphragm wear.
  • Extended-Wear enhancements: Engineered for durability in abrasive environments, featuring thicker wetted castings and wear-resistant components for long-term reliability.

  • Abrasive and Solid-Laden Fluids: With wear pads and thickened castings, ideal for severe, high-abrasion environments.
  • Gas-Entertained or Settling Solid Fluids: Tailored porting options ensure performance efficiency and durability.
  • Industrial Chemical Processing: Designed to manage a wide range of chemical types with material compatibility options.

Why Choose SANDPIPER HEAVY DUTY BALL VALVE PUMPS

ESADS+: Minimizes downtime with fast, on-site serviceability, reducing repair times by as much as 90%

Enhanced Durability for Longevity: Reinforced diaphragm wear pads and heavy-duty bushings ensure performance in high-stress applications.

Proven Evolution Engineering: Optimized for performance through trusted designs and advanced engineering for unmatched reliability.
HDB2 and HDB50 Metallic AODD heavy-duty ball valve pumps, available in 2-inch (50 mm) sizes for industrial applications in challenging environments.



FOR MORE INFORMATION, CLICK HERE:
HDB2 and HDB50 Metallic 2" (50 mm) AODD – Heavy-Duty Ball Valve Pump
