Application
Data transmission cable, control and connecting cable predominantly for transmission of analog and digital signals in process controlled facilities in measurement and control technology. For fixed laying and flexible applications with underfined cable routing and without tensile stress. Suitable for use in dry and humid rooms. Outdoor use only with UV-protection, no laying underground.
Technical Specification :
| Conductor material | Bare copper stand |
| Core insulation | PVC |
| Stranding | Stranded in layers |
| Outer sheath | PVC |
| Rated voltage | Uo/U: 250V; peak-voltage on 0, 14mm² 350V; >0,14mm² 500V |
| Operat. temp. fixed min/max | -30 °C / +80 °C |
| Operat. temp. moved min/max | -5 °C / +70 °C |
| Burning behavior | Self-extinguishing and flame retardant acc. to IEC 60332-1 |
