QTG70ML-WIZ 70mm Wireless LED Steady/ Flashing Tower Light Max.85dB

QTG70ML-WIZ Ø70mm Wireless LED Steady/ Flashing Tower Light
Max.85dB

Can remotely monitor and control the status of tower lights using a PC or smartphone




QTG70ML-WIZ

Ø70mm Wireless LED Steady/ Flashing Tower Light
Max.85dB

Can remotely monitor and control the status of tower lights using a PC or smartphone



【Features】

• Ideal solution for building smart factories with state of the art technology
• Wireless monitoring and control of signal tower light via PC or smartphone
• WIZ series can integrate mismatch among old machineries, latest equipment and various brands

【Main characteristics】

• Possible to control the product via external communication and PC application software
• The product transfers visual and audible warning signals as well as data being monitored remotely by means of wireless communication.
• Productivity and failure rate management for each machine
• Cost effective solution for an advanced manufacturing network system
• Mesh topology uses 2.4GHz local wireless telecommunication to enable stable communication even under the harsh environmental conditions.
• The multi-hop feature allows for long distance communication up-to 10 HOP (100 meter between the units).
• Production equipment relocation would be convenient because the wireless network system does not require a telecommunication cable.
• 5 built-in buzzer tones are available.
• Volume : Buzzer – Max. 85dB at 1m
• Protection rating : IP54/IP65
• Compliant with RoHS directive

【Operational environment】

• OS Support: Windows 10
• Library Support: C#(64bit only)
• Wireless communication protocol : Zigbee(IEEE802.15.4)
• 2.4GHz radio communication available

Product Specifications

Model number	Layer	Voltage	Current	Certificates	Weight	Color
QTG70ML-WIZ Steady QTG70ML-WIZ-BZ Steady /w built-in buzzer QTG70MLF-WIZ Steady/Flashing QTG70MLF-WIZ-BZ Steady/Flashing /w built-in buzzer QTGA70ML-WIZ Steady QTGA70ML-WIZ-BZ Steady /w built-in buzzer QTGA70MLF-WIZ Steady/Flashing QTGA70MLF-WIZ-BZ Steady/Flashing /w built-in buzzer	1	DC12V DC24V AC110V~220V	0.150A 0.110A Max. 0.070A		0.45kg 0.45kg 0.55kg	R-Red
	2	DC12V DC24V AC110V~220V	0.240A 0.160A Max. 0.100A		0.59kg 0.59kg 0.69kg	R-Red  G-Green
	3	DC12V DC24V AC110V~220V	0.330A 0.220A Max. 0.120A		0.80kg 0.80kg 0.90kg	R-Red  A-Amber  G-Green
	4	DC12V DC24V AC110V~220V	0.420A 0.270A Max. 0.150A		0.95kg 0.95kg 0.95kg	R-Red  A-Amber  G-Green  B-Blue
	5	DC12V DC24V AC110V~220V	0.510A 0.320A Max. 0.170A		1.10kg 1.10kg 1.20kg	R-Red  A-Amber  G-Green  B-Blue  W-White

※ AC type model has a free-voltage range of 100V-240V.
