Yellow and White.
Also, consider Red/Blue/Green thermal ribbons.
TESTING
Testing includes Salt Mist Spray according to Lloyds Register Type Approval System and High/Low Temperature.
PRINTING
Print via Fox-in-a-Box® thermal printer.
| Specification | Description |
| Material | Halogen free flame retardant single wall matt printable polyolefin |
| Shrink Ration | 2:1 |
| Minimum Shrink Temperature | 115°C ( 239°F) – fully recovered |
| Operating Temperature | -40°C to +105°C (-40°F to 221°F) |
| Diaeletic Strength | ≥ 20 kV/mm |
| RoHS | RoHS Complaint |
| Printing | Silver Fox DTP-1 thermal printer |
| Ribbon | TSR3/300/60 |
| Network Rail | Authorised for Use |
| Item Code |
Cable
ODØ Exp.
(mm)
|
Cable
ODØ rec.
(mm)
|
Labels
Per Roll
|
Pack
Qty
|
Colour |
| DSSB-CIA-LHLZ/C/L50/2.4-1.2T(PF)Y | 2.4 | 1.2 | 1500 | 1 Roll | Yellow |
| DSSB-CIA-LHLZ/C/L50/2.4-1.2T(PF)W | White | ||||
| DSSB-CIA-LHLZ/C/L50/3.2-1.6T(PF)Y | 3.2 | 1.6 | 1000 | Yellow | |
| DSSB-CIA-LHLZ/C/L50/3.2-1.6T(PF)W | White | ||||
| DSSB-CIA-LHLZ/C/L50/4.8-2.4T(PF)Y | 4.8 | 2.4 | Yellow | ||
| DSSB-CIA-LHLZ/C/L50/4.8-2.4T(PF)W | White | ||||
| DSSB-CIA-LHLZ/C/L50/6.4-3.2T(PF)Y | 6.4 | 3.2 | Yellow | ||
| DSSB-CIA-LHLZ/C/L50/6.4-3.2T(PF)W | White | ||||
| DSSB-CIA-LHLZ/C/L50/9.5-4.8T(PF)Y | 9.5 | 4.8 | 500 | Yellow | |
| DSSB-CIA-LHLZ/C/L50/9.5-4.8T(PF)W | White | ||||
| DSSB-CIA-LHLZ/C/L50/12.7-6.4T(PF)Y | 12.7 | 6.4 | Yellow | ||
| DSSB-CIA-LHLZ/C/L50/12.7-6.4T(PF)W | White | ||||
| DSSB-CIA-LHLZ/C/L50/19.1-9.5T(PF)Y | 19.1 | 9.5 | 2500 | Yellow | |
| DSSB-CIA-LHLZ/C/L50/19.1-9.5T(PF)W | White | ||||
| DSSB-CIA-LHLZ/C/L50/25.4-12.7T(PF)Y | 25.4 | 12.7 | Yellow | ||
| DSSB-CIA-LHLZ/C/L50/25.4-12.7T(PF)W | White | ||||
| DSSB-CIA-LHLZ/C/L50/38.1-19.1T(PF)Y | 38.1 | 19.1 | Yellow | ||
| DSSB-CIA-LHLZ/C/L50/38.1-19.1T(PF)W | White |
| Test | Method |
| Flame Retardant | UL224 |
|
Fire Testing of Materials and Components for Trains -
Oxygen Index & Flue Gas Density
|
EN 45545-2 |
