Description
Highly Energy-efficient Centre Pivot Windows FTT
FTT U8 Thermo with coefficient Uw=0.58W/m2K
FTT U6 - with coefficient Uw=0.80W/m2K
FTT R3 - with coefficient Uw=0.81W/m2K, Rw=40dB
-
Installation range: 15-70o.
-
Wide range of accessories
|
Technical Specification: |
FTT U6 |
FTT R3 |
FTT U8 Thermo |
|
window U-value: |
0,80 W/m2K |
0,81 W/m2K |
0,58 W/m²K |
|
glazing U-value: |
0,5 W/m2K |
0,5 W/m2K |
0,3 W/m²K |
|
acoustic insulation Rw: |
38 dB |
40 dB |
36 dB
|
|
glazing unit: |
6HT-18-4H-18-33.2T |
8H–16Tg–4HT–18Tg–33.1SIT |
4HT-12-4HT-12-4HT-12-4HT |
|
inert gas filled with panes: |
argon |
argon |
krypton |
|
toughened external glass: |
+ |
+ |
+ |
|
varnishing: |
twice |
twice |
twice |
|
seals: |
five |
five |
five |
|
handle: |
Elegant |
Elegant |
Elegant |
Characteristic:
-
Special roof windows intended for energy-efficient and passive construction. The glazing unit is set in a specially designed sash frame. It has wider wooden profiles, compared with a standard window. This design minimizes the phenomenon of thermal bridges and provides better insulation of the window. FTT Thermo U8 window with a heat transfer coefficient of Uw = 0.58 W/m2K is the warmest roof window on the market. Supplied and installed complete with flashing EHV-AT Thermo. As standard, it is also equipped with a set of insulation flashings XDK consisting of insulation set XDP and air-tight flashing XDS.Windows opened via pivot with hinges positioned above the window mid-height, thanks to which even a tall person can comfortably stand upright by the open window. Special window structure utilising wider sash frames and quadruple sealing system.
-
Easy washing the external glass and fastening awning blind thanks to a special bolt which blocks the sash when rotated through 180°.
-
Increased burglary-resistance – topSafe system.
