Description
SAFT LS14500
Primary Li-SOCl2 cell
High energy density 3.6 V AA-size bobbin cell
Saft's LS 14500 cell is ideally suited for long-term applications [typically from 5 to 20+ years), featuring low base currents and periodic pulses.
Benefits
◼ High capacity and high energy [1122 Wh/l and 520 Wh/kg)
◼ High voltage response, stable during most of the lifetime of the application
◼ Wide operating temperature range [-60°C/+85°C)
◼ Low self-discharge compatible with long operating life [less than 1% per year of storage, at + 20 °C, after 1 year)
◼ Superior resistance to corrosion
◼ Low magnetic signature
Key features
◼ Bobbin construction
◼ Well controlled passivation
◼ Hermetic construction with glass-to metal seal
◼ Stainless steel container
◼ Non-flammable electrolyte
◼ RoHS and REACH compliance
◼ Made in France, China, UK
Designed to meet all major quality, safety and environment standards
◼ Safety: UL 1642, IEC 60086-4
◼ ATEX: IEC 60079-11 part 10.5 [T4 rating at+ 40 °C]
◼ Transport: UN 3090 and UN 3091
◼ Quality: ISO 9001, Saft World Class continuous program
Typical applications
◼ Utility Metering
◼ Internet of Things
◼ Tracking systems
◼ Alarms and security
◼ Connected sensors
◼ Medical devices
