Description

22^kW
POWER TYPE

RM11,088

Supply, Installation, Commissioning & Training
Installation Available Nationwide Malaysia
OCPP 1.5J

FEATURES

INSTALLATION PACKAGE

22^kW
POWER TYPE

RM11,088

EV Junction Box Enclosure
3 Phase 4 Pole MCB 40A (Branded)
3 Phase 4 Pole RCCB 40A (Branded)
3 Phase 4 Pole Isolator Switch 35A (Branded)
Up to 15m of 6mm² X 5C PVC Cable c/w PVC Conduit

GENERAL SPECIFICATION

Charger	AC
Color	White + Black
Charging mode	Mode 3
Dimensions	200 x 335 x 315mm (without cable)
Weight	4kg (without cable)
Cable Length	Nil
Operating Temperature	-5° C to 45° C
Storage Temperature	-40° C to 60° C

CONNECTIVITY & USER INTERFACE

Connectivity	4G & TCP/IP
User Identification	App & OCPP 1.5J
User Interface	App
Charger Status Information	RGB LED
Communication Protocol	OCPP 1.5J & TCP/IP

ELECTRICAL SPECIFICATION

Maximum Charging Power	22kW (3Phase)
Rated Voltage AC ± 10%	360V to 440V (22kW)
Rated Current	32A (22kW - 3Phase)
Connector Type	Type 2 Socket
Protection Rating	IP54/ IK10
Residual Current Detection	DC 6 mA

Vehicle Charger / Car Charger / Electronic / Charging Stations / Wallbox / Savings /. Circontrol eNEXT PARK EV Charging Module from Saturn Pyro is the best available in Malaysia. High performance and cost effective Power Energy Meter with 4-quadrant measurement (consumption and generation). Suitable for Medium or Low voltage installations, in both 3 or 4-wire three-phase circuits, two-phase circuits with or without neutral, single-phase circuits or ARON connections. Available in Penang, KL, Selangor, Johor, Sabah, Sarawak & anywhere in Malaysia & Singapore.

Pengecas Kenderaan / Pengecas Kereta / Elektronik / Stesen Pengecasan / Wallbox / Penjimatan /. Circontrol eNEXT PARK Charging Module dari Saturn Pyro adalah yang terbaik di Malaysia. Prestasi tinggi dan kos tenaga Tenaga Tenaga yang berkesan dengan pengukuran 4-kuadran (penggunaan dan generasi). Sesuai untuk pemasangan voltan sederhana atau rendah, dalam litar tiga fasa 3 atau 4-wayar, litar dua fasa dengan litar fasa tunggal atau ARON atau tanpa neutral neutral. Boleh didapati di Pulau Pinang, KL, Selangor, Johor, Sabah, Sarawak & di mana sahaja di Malaysia & Singapura.
