Description

PHILIPS PROFESSIONAL LAMP FLUORESCENT MASTER PL-C 13W/827/830/840/865 2P 1CT/5X10CC

927904882701-MASTER PL-C 13W/827/2P 1CT/5X10CC
927904883001-MASTER PL-C 13W/830/2P 1CT/5X10CC
927904884002-MASTER PL-C 13W/840/2P 1CT/5X10CC
927904886502-MASTER PL-C 13W/865/2P 1CT/5X10CC

MASTER PL-C 2 Pin

MASTER PL-C 13W/827/830/840/865 2P 1CT/5X10BOX

E-MASTER PL-C is an efficient medium-wattage compact fluorescent lamp, typically used in general downlights for retail, hospitality and office applications. The original Philips-invented bridge technology guarantees optimum performance in the application, enabling more light and higher efficacy than the bended technology. The 2-pin version is designed for operation on electromagnetic gear and is provided with a plug-in/pull-out lamp base.

Warning and safety

Use only with electromagnetic control gear
Lamp light technical and electrical characteristics are influenced by operating conditions, i.e. lamp ambient temperature and operating position
Dimming is not possible
A lamp breaking is extremely unlikely to have any impact on your health. If a lamp breaks, ventilate the room for 30 minutes and remove the parts, preferably with gloves. Put them in a sealed plastic bag and take it to your local waste facilities for recycling. Do not use a vacuum cleaner.

Product Data

General Information

Cap-Base : G24D-1 [ G24d-1]
Life To 10% Failures (Nom) : 6500 h
Life to 50% Failures (Nom) : 10000 h
LSF 2000 h Rated : 99 %
LSF 4000 h Rated : 98 %
LSF 6000 h Rated : 92 %
LSF 8000 h Rated : 78 %

Light Technical

Color Code 827 [ CCT of 2700K], 830 [ CCT of 3000K], 840 [ CCT of 4000K], 865 [ CCT of 6500K]
Luminous Flux (Nom) : 925 lm, 925 lm, 925 lm, 845 lm
Luminous Flux (Rated) (Nom) : 925 lm, 925 lm, 925 lm, 845 lm
Color Designation : Incandescent White, Warm White (WW), Cool White (CW), Cool Daylight
Correlated Color Temperature (Nom) : 2700 K, 3000 K, 4000 K, 6500 K
Luminous E€cacy (rated) (Nom) : 69 lm/W, 69 lm/W, 69 lm/W, 63 lm/W
Color Rendering Index (Nom) : 83, 82, 82, 80
LLMF 2000 h Rated : 92 %, 92 %, 92 %, 90%
LLMF 4000 h Rated : 87 %, 87 %, 87 %, 85%
LLMF 6000 h Rated : 83 %, 83 %, 83 %, 81%
LLMF 8000 h Rated : 81 %, 81 %, 81 %, 77%

Operating and electrical

Power (Rated) (Nom) : 13.4 W
Lamp current (nom.) : 0.170 A

Temperature

Design temperature (nom.) : 28 °C

Control and dimming

Dimmable : No

Mechanical and housing

Cap-base infrormation : 2Pins

Approval and application

Mercury (Hg) content (nom.) : 1.4 mg
Energy consumption kWh/1,000 hours : 17 kWh

Product Data

Full product code : 871150062081100/871150026922500/871150062086600/871150063523500
Order product name : MASTER PL-C 13W/827/2P 1CT/5X10BOX, MASTER PL-C 13W/830/2P 1CT/5X10BOX, MASTER PL-C 13W/840/2P 1CT/5X10BOX, MASTER PL-C 13W/865/2P 1CT/5X10BOX
EAN/UPC - Product : 8711500620811, 8711500269225, 8711500620866, 8711500635235
Order code : 927904882701/927904883001/927904884002/927904886502
Numerator - Quantity Per Pack : 1
Numerator - Packs per outer box : 50
Material Nr. (12NC) : 927904882701/927904883001/927904884002/927904886502
Net Weight (Piece) : 53.600 g
ILCOS Code : FSQ-13/27/1B-I-G24d=1, FSQ-13/30/1B-I-G24d=1, FSQ-13/40/1B-I-G24d=1, FSQ-13/65/1B-I-G24d=1
