SP-UV 300

The SP-UV 300 is a split beam spectrophotometer in the production series of Spectrum Instruments. It gets a technology patent - ''space seperated double beam, Non-Symmetric vertical optical path''. Compared with traditional double beam technology, simplified optical path improves reliability. The''width narrow and depth deep'' design saves placement room

Features:
- Split Beam Spectrophotormeter
- Wavelength range 190 -1100rpm
- Spectral Bandwidth 2nm
- Motorized wavelength setting
- 8 inch color touchscreen
- Sprectrum scan function
- Detector 2 Silicon Photodiode

Performance Specification:
Optical Ssystem: 1200 lines/mm diffraction grating monochromator
Light path: 10mm -100mm
Spectral bandwidth: 2nm
Wavelength range: 190 - 1000nm ( 0.1nm increament )
Wavelength ccuracy: +- 0.5nm
Wavelength repeatability: +- 0.3nm
Stray light: < 0.5% T ( at 220nm Nal & 340nm, NaNO2 )
