Specifications
- Porting Size: 1/4" NPT (Internal)
1/2" NPT(External)
- Capacity: 0 - 5 gpm (19 lpm)
- Air Distribution Valve: No - lube, no-stall design
- Solids Handling: 1/32" (1 mm)
- Heads up to: 100 psi or 231 ft of water
(7 bar or 70 meters)
- Max Operating Pressure: 100 psi (7 bar)
- Weight: Polypropylene - 3.3 lbs(1.5 kg)
PVDF - 3.9 lbs(1.8 kg)
Description
PB 1/4" (6 mm) NON-METALLIC AODD - STANDARD DUTY NON-METALLIC BALL VALVE PUMP
The SANDPIPER PB ¼" (6 MM) NON-METALLIC AODD Pump is engineered specifically for original equipment manufacturers (OEMs), offering exceptional flexibility and performance in various applications such as pharmaceutical, food and beverage or chemical industry.
Sandpiper Non-Metallic AODD Pump Key Features:
- Quiet Operation: One of the quietest pumps in its class, ensuring minimal noise disruption during operation
- Patented Air Valve System: Provides non-stalling, non-icing, and lube-free operation for years of dependable service
- Material options: Available in polypropylene, conductive acetal, and PVDF (Kynar), suitable for various chemical applications.
- Multiple Porting Options: Suction and discharge manifolds feature versatile porting options to accommodate different setups.
|
 |
Application
- Dispensing: Ideal for inks, coatings, adhesives, oils, and a wide range of chemicals
- Versatile Mounting: Can be mounted horizontally, vertically, or with end suction configurations to fit various system designs.
Why Choose SANDPIPER AIR OPERATED DOUBLE DIAPHRAGM PUMP?
- Ultra-Compact Design: Lightweight and efficient, allowing for easy transportation and installation in tight spaces.
- Durable construction: designed for reliability, ensuring long service life even in demanding conditions.
- Abrasion resistance: Features a low-friction surface for enhanced durability and reduced wear.
- Easy Serviceability: The externally serviceable main air valve simplifies maintenance and minimizes downtime
