TDS-12.0H SR
TDS-12.0H SR



TDS-12.0H SR

Tri Automaxx Sdn Bhd flag
分类: TDS 当前有货
欲了解更多详情，请游览我们的官方网站 triautomaxx.com
游览官方网站 联络我们
详情

Features


Specifications
Line Pull : 5,442kgs/12,000lbs
Motor : 12V/24V  series wound
Gear Train : Three stage
Gear Ratio : 216:1
Freespooling Clutch : Rotating ring gear
Synthetic Rope  Size : Φ11/28'×90'(Φ10mm×27.4m)
Drum Size : Φ2.5'×9'(Φ63.5mm×229mm)


Line Pull
Layer of Wire Rope Max Line Pull
1 12,000lbs/5,442kgs
2 9,789lbs/4,445kgs
3 8,273lbs/3,760kgs
4 7,199lbs/3,255kgs


Line Speed and AMP Draw (1st Layer of Synthetic Rope On The Drum)
Load Line Speed AMP Draw(12V) AMP Draw(24V)
No Load 31FPM/9.5MPM 60 60
2,000lbs/907kgs 13.9FPM/4.2MPM 116 87
4,000lbs/1,814kgs 11.5FPM/3.5MPM 150 121
6,000lbs/2,722kgs 9.9FPM/3.0MPM 198 167
8,000lbs/3,650kgs 8.6FPM/2.6MPM 240 190
9,500lbs/4,309kgs 7.9FPM/2.4MPM 268 229
11,000lbs/5,000kgs 7.2FPM/2.2MPM 300 244
12,000lbs/5,442kgs 5.9FPM/1.8MPM 320 252


Standard Accessories
Controller : TA-0906
Synthetic Rope With Hook : -
Hawse fairlead : TA-0921
Control Unit : TA-0949/12V & TA-0950/24V
Mounting Hardware : -
Handsaver Strap : -


Package
Winch Weigh : 33kgs/72.6lbs
Gross Weight : 35kgs/77lbs
Box Dimension : 647×198×410 mm(25.5'×7.8'×16.1')


Dimension (mm)
