Features
| Specifications | ||
| Line Pull | : | 4,083kgs/9,000lbs |
| Motor | : | 12V/4.8HP |
| Gear Train | : | Three stage |
| Gear Ratio | : | 254:1 |
| Brake | : | Flanges brake |
| Freespooling Clutch | : | Rotating ring gear |
| Wire Rope Size | : | Φ5/16'×100'(Φ8.0mm×30m) |
| Wire Rope Type | : | Aircraft A7×19 |
| Drum Size | : | Φ2.5'×9'(Φ63.5mm×229mm) |
| Line Pull | |
| Layer of Wire Rope | Max Line Pull |
| 1 | 9,000lbs/4,083kgs |
| 2 | 7,370lbs/3,342kgs |
| 3 | 6,230lbs/2,825kgs |
| 4 | 5,390lbs/2,447kgs |
| Line Speed and AMP Draw (1st Later of Rope On The Drum) | ||
| Load | Line Speed | AMP Draw(12V) |
| No Load | 34FPM/10.1MPM | 65 |
| 2,000lbs/907kgs | 20FPM/6.1MPM | 130 |
| 4,000lbs/1,814kgs | 17FPM/5.2MPM | 200 |
| 6,000lbs/2,722kgs | 13FPM/4.0MPM | 320 |
| 9,000lbs/3,629kgs | 6.5FPM/2.0MPM | 400 |
| Standard Accessories | ||
| Controller | : | TA-0906 |
| Wire Rope With Hook | : | - |
| 4 Way Roller Fairlead | : | TA-0903 |
| Control Unit | : | TA-0909 |
| Mounting Hardware | : | - |
| Handsaver Strap | : | - |
| Package | ||
| Winch weight | : | 39kgs/85.8lbs |
| Gross Weight | : | 44.5kgs/97.9lbs |
| Box Dimension | : | 560×198×405 mm(22'×7.8'×16') |
| Dimension (mm) |
