| GENERAL | |
| Warm up time | 30 seconds or less, 22 seconds or less if the main power is on (At room temperature 23ºC) |
| First output speed | B/W:5.9 seconds |
| Colour: 8.1 seconds | |
| Continuous output speed | B/W: 20/25 ppm |
| Colour: 20/25 ppm | |
| Memory | Standard: 4GB |
| Maximum: 4GB (Optional) | |
| HDD: 160GB or larger (Usable space: 128 GB) | |
| Dimensions (W x D x H) |
W 590 x D 659 x H 768 mm
W 590 x D 659 x H 962 mm (when optional 1 Tray Module is installed.) W 616 x D 659 x H 1119 mm (when optional 1 Tray Module with cabinet is installed.) W 616 x D 659 x H 1119 mm (when optional 3 Tray Module is installed.) |
| Weight |
68kg
87 kg (when optional 1 Tray Module is installed.) 92 kg (when optional 1 Tray Module with cabinet is installed.) 95 kg (when optional 3 Tray Module is installed.) |
| Power source | AC220-240 V +/- 10 %, 8 A, 50/60 Hz common |
| COPIER | |
| Multiple copy | Up to 999 |
| Resolution | 600 dpi |
| Zoom | From 25 to 400% (in 1% steps) |
| PRINTER | |
| Printer language | Standard: PCL 5 / PCL 6 |
| Option | Adobe® PostScript® 3™ |
| Resolution | 600 x 600 dpi, 1200 x 2400 dpi |
| Interface | Standard: Ethernet 1000BASE-T / 100BASE-TX / 10BASE-T, USB2.0 |
| Supported Operating System |
Standard:
[PCL Driver] Windows® 10 (32bit), Windows® 10 (64bit), Windows® 8.1 (32bit) Windows® 8.1 (64bit), Windows® 8 (32bit), Windows® 8 (64bit) Windows® 7 (32bit), Windows® 7 (64bit), Windows Vista® (32bit) Windows Vista® (64bit), Windows Server® 2012 R2 (64bit) Windows Server® 2012 (64bit), Windows Server® 2008 R2 (64bit) Windows Server® 2008 (32bit), Windows Server® 2008 (64bit) Windows Server® 2003 (32bit), Windows Server® 2003 (64bit) [Mac OS X Driver] OS X 10.10/10.9/10.8, Mac OS X 10.7/10.6/10.5 Optional: [Adobe® PostScript® 3TM Driver] Windows® 10 (32bit), Windows® 10 (64bit), Windows® 8.1 (32bit) Windows® 8.1 (64bit), Windows® 8 (32bit), Windows® 8 (64bit) Windows® 7 (32bit), Windows® 7 (64bit), Windows Vista® (32bit) Windows Vista® (64bit), Windows Server® 2012 R2 (64bit) Windows Server® 2012 (64bit), Windows Server® 2008 R2 (64bit) Windows Server® 2008 (32bit), Windows Server® 2008 (64bit) Windows Server® 2003 (32bit), Windows Server® 2003 (64bit) OS X 10.10/10.9/10.8, Mac OS X 10.7/10.6/10.5 |
| Windows® environments: | Windows® XP, Windows® Vista, Windows® 7, Windows® Server2003, Windows® Server2003R2, Windows® Server 2008, Windows® Server 2008R2, Windows® Server 2012 |
| Mac OS environments: | Mac OS X Native: v.10.5 or later |
| UNIX environments: | UNIX Sun® Solaris, HP-UX, SCO |
| OpenServer, RedHat® Linux Enterprise, | |
| IBM® AIX | |
| SCANNER | |
| Scan speed | Duplex Automatic: B/W: 55 ppm, Colour: 55 ppm |
| Document Feeder: [Fuji Xerox Standard Paper (A4 LEF), 200dpi, to Folder.] | |
| Resolution | 600 x 600 dpi, 400 x 400 dpi, 300 x 300 dpi, 200 x 200 dpi |
| File format | TIFF, JPEG, PDF, High compression PDF, PDF-A |
| Bundled drivers | Network TWAIN |
| Scan to e-mail | SMTP,POP, IMAP4 |
| Scan to folder | SMB, FTP, NCP |
| FAX (OPTION) | |
| Circuit | Telephone subscriber line, PBX, Fax communication (PSTN), Maximum 3 ports (G3-3 ports) |
| Compatibility | ITU-T (CCITT) G3 |
| Modem speed | Maximum 33.6 Kbps |
| Resolution | Standard: 8 x 3.85 line/mm, 200 x 100dpi, |
| 8 x 7.7 line/mm, 200 x 200 dpi, | |
| Option: 8 x 15.4 line/mm, 16 x 15.4 line/mm, | |
| 400 x 400 dpi | |
| Compression method | MH, MR, MMR, JBIG |
| Transmission speed | 2 seconds and more but fewer than 3 seconds |
| Memory capacity | Standard: 4 MB |
| Maximum: 28 MB | |
| PAPER HANDLING | |
| Recommended paper size |
Max: A3, 11 x 17″
Min: A5 [Postcard (100 x 148 mm) and Envelope Monarch (191 x 98 mm) when using Bypass Tray] Image loss width: Lead Edge 4.0 mm, Trail Edge 2.0 mm, Right & Left Edges 2.0 mm |
| Paper input capacity | Standard: 500 sheets x 1-tray + Bypass Tray 96 sheets |
| Maximum: 2096 sheets [Standard + 3 Tray Module] | |
| Optional: 1 Tray Module / 1 Tray Module with Cabinet: 500 sheets x 1-tray | |
| 3 Tray Module: 500 sheets x 3-tray | |
| Paper output capacity | Upper Center: 250 sheets (A4 LEF) |
| Lower Center: 250 sheets (A4 LEF) | |
| Paper weight | Paper tray(s): 60 – 256 g/m2 |
| Bypass tray: 60 – 216 g/m2 | |
| ECOLOGY | |
| Power consumption | 1.76 kW or less (AC220 V +/- 10%), 1.92 kW or less (AC240 V +/- 10%) |
| Ready mode : 78 W or less (AC220 V +/- 10%) | |
| Sleep mode : 1.0 W or less (AC220 V +/- 10%) | |
