This is the 2013 Newest BaoFeng UV-82L dual band radio. It is a micro-miniature multiband FM transceiver with extensive receive frequency coverage, providing local-area two-way amateur communications along with unmatched monitoring capability.
Functions:
1. Dual PTT keys (Top of PTT selects TX (A). Bottom of PTT selects (B))
2. Dua-Band handheld transceiver with display function menu on the display"LCD"
3. A/B band independent operation
4. 128 groups channels storage
5. Incorporates 105 codes"DCS"and 50 privacy codes "CTCSS" programmable
6. CTCSS & DCS Scanning/ CTCSS & DCS Direct input
7. Emergency Alarm
8. Tri-color background light selectable
9. 0~9 grades VOX selectable
10.Display A/B BEEP tone (A tone can be added to the end of Received signal)
11.FM radio(65MHz-108MHz) and 25 stations storage
12.1750Hz Brust
13.Crossband reception/transmission
14.Channel Monitor
15.Battery Saving function"SAVE"
16.Built-in key lock
17.Channel Step: 2.5/5/6.25/10/12.5/25KHz
18.Low Battery Alert
19.ROGER SET
20.Emergency Alert
21.25KHz/12.5KHz Switchable
22.FM Radio (65.0MHz-108.0MHz)
23.Large LCD Display
24.LED Flashlight
25.Hight /Low RF Power Switchable
26.Function"OFFSET"(frequency offset for repeater access)
27.Tone end of transmission
28.Programmable by PC
29.Wide/Narrow Band(25kHz/12.5kHz)
30.Transmitter time-out timer(TOT)
31.High/Low TX power selectable
32.Busy channel lock-out(BCLO)
Specification:
|
General |
|
|
Frequency Range |
65-108MHz(FM Receive only) |
|
136-174MHZ and 400-520MHZ (TX/RX) |
|
|
Memory Channel |
Up to 128 channels |
|
Frequency Stability |
±2.5ppm |
|
Antenna |
18CM High gain Dual Band antenna |
|
Antenna Impedance |
50Ohm |
|
Supply Voltage |
Rechargeable Lithium-Ion 7.4V |
|
Mode of operation |
Simple or semi-duplex |
|
Frequency Stability |
2.5ppm |
|
Frequency Step |
2.5 / 5 / 6.25 / 10 / 12.5 / 20 / 25kHz |
|
Dimension(W x H x D) |
286 x 52 x 30 mm (included antenna) |
|
Weight |
238g (including battery, antenna) |
|
Power adapter |
Input: AC100-240V, 50-60Hz; Output: DC10V/500mA; |
|
Transmitter |
|
|
RF power |
5W / 1W |
|
Modulation Mode |
16kF3E / 11kF3E(W/N) |
|
Maximum deviation |
<=5kHz(Wide) / <=2.5kHz(Narrow) |
|
Spurious Radiation |
7W |
|
Adjacent Ch. power |
-65dB(Wide) / -60dB(Narrow) |
|
Receiver |
|
|
Intermodulation |
60dB |
|
Audio Output |
1W |
|
Maximun Deviation |
<=5kHz / <=2.5kHz (W / N) |
|
Spurious emission |
<-60dB |
Package:
1x BAOFENG UV-82L (VHF 136-174Mhz,UHF 400-520Mhz) Two-Way Radio
1x 7.4V Li-ion Battery
1x BAOFENG Original Earpiece with PTT Button
1x 18cm Dual Band Booster Antenna
1x Power Adapter
1x Belt Clip
1x Hand Strap
1x Battery Charger
1x User Manual
