ROOF & TRUSS PANELS
Metaldek®24 Drill & Screw Roof Panel
Metaldek®24 Drill & Screw Roof Panel



Metaldek®24 Drill & Screw Roof Panel

Overseametal Sdn Bhd flag
分类: ROOF & TRUSS PANELS 当前有货
欲了解更多详情，请游览我们的官方网站 overseametal.com
游览官方网站 联络我们
详情

OSM® Metaldek® 24 is attractive yet affordable which is why it is widely accepted in the market. This profile is highly recommended for Roof Design. With its 5 high reinforcing ribs, which is 24mm, the possibility of water entry from the side lappings is low. The provision of anti-capillary groove serves as a break to stop upward travel of water due to surface tension. The high ribs allow roof pitch to be as low as 5˚.



  • √  Strong rib design
  • √  Wide effective coverage of 762mm
  • √  Easy to handle and install


Insulation Package

Materials available in

Zinc Coated
100% Zinc Coated Steel

Aluzinc
55% Aluminium, 43.5% Zinc, 1.5% Silicon

Aluminium Stucco Embossed
100% Aluminium

Stainless Steel
100% Stainless Steel


Materials
Zinc Coated
100% Zinc Coated Steel
Series
Thickness (TCT) 0.35 , 0.40 0.47 , 0.48 0.50 0.56
Sirim Corrosion Class C3 C4-T C5-I C5-M
Suitable for: Urban or industrial atmospheres, moderate sulphur dioxide pollution, coastal area with low salinity Industrial areas and coastal  areas with moderate salinity Industrial areas with high humidity and aggresive atmosphere Coastal and offshore areas with very high salinity
Protection Coating Z120 Z180 Z275 Z275
MyHijau / Energy Star √ √ √ √
Warranty (up to) 10 yrs - Corr 20 yrs - Corr
10 yrs - Color		 30 yrs - Corr
10 yrs - Color
5 yrs - Dirt		 30 yrs - Corr
15 yrs - Color
Paint System Polyester Polyester Superdurable Polyester Pvdf


Materials
Aluzinc
55% Aluminium,
43.5% Zinc, 1.5% Silicon
Series
Thickness 0.48mm - AZ150 Coating
Suitable for: Low pollution, rural areas
Warranty (up to) Up to 25 years perforation warranty


Materials
Aluminium Stucco Embossed
100% Aluminium
Thickness 0.25mm / 0.70mm
Suitable for: Industrial areas with high humidity and aggresive atmosphere

Heavy industrial factories
Warranty (up to) Up to 35 years perforation warranty


Materials
Stainless Steel
100% Stainless Steel
Thickness 0.35mm
Suitable for: Industrial areas with high humidity and aggresive atmosphere

Heavy industrial factories
Warranty (up to) Up to 50 years perforation warranty



  • 10kg/m3 Fiber Glass Wool
  • Aluminium Leno Foil (Alu/M)
  • Achieving good thermal resistance and sound transmission class



  • 16kg/m3 Fiber Glass Wool / 40kg/m3 Rockwool
  • Aluminium Woven Foil (Alu/M)
  • Achieving great thermal resistance and sound transmission class


  • 32kg/m3 Fiber Glass Wool / 80kg/m3 Rock Wool with Zed Spacer
  • Aluminium Tall Woven Foil (Alu/M)
  • Achieving excellent thermal resistance and sound transmission class

Insulation Package

** Roof insulation system can be customised according to projects.
