PHILIPS PROFESSIONAL LAMP FLUORESCENT MASTER PL-L 36W/827/830/840/865/4P 1CT/25 927903408270 927903408370 927903408470 927903486570

927903408270 - MASTER PL-L 36W/827/4P 1CT/25
927903408370 - MASTER PL-L 36W/830/4P 1CT/25
927903408470 - MASTER PL-L 36W/840/4P 1CT/25
927903486570 - MASTER PL-L 36W/865/4P 1CT/25

MASTER PL-L 4 Pin

MASTER PL-L 36W/827/830/840/865/4P 1CT/25

MASTER PL-L is a medium to high-wattage linear compact fluorescent lamp, typically used for general-illumination ceiling luminaires in retail, hospitality and office applications demanding higher lighting levels. The original Philips-invented bridge technology guarantees optimum performance in the application, enabling more light and higher efficacy than the bended technology. It is designed for operation on electromagnetic as well as electronic HF control gear and is provided with a plug-in/pull-out lamp base.

Warning and safety

Lamp light technical and electrical characteristics are influenced by operating conditions, i.e. lamp ambient temperature and operating position as well as applied control gear
Shorter lamp life when often switching and not well pre-heated electrodes
A lamp breaking is extremely unlikely to have any impact on your health. If a lamp breaks, ventilate the room for 30 minutes and remove the parts, preferably with gloves. Put them in a sealed plastic bag and take it to your local waste facilities for recycling. Do not use a vacuum cleaner.

Product Data

General Information

Cap-Base : 2G11 [ 2G11]
Life To 10% Failures (Nom) : 10000 h
Life to 50% Failures (Nom) : 15000 h
Life to 50% Failures Preheat (Nom) : 20000 h
System Description : - / na[-]
LSF 2000 h Rated : 99 %
LSF 4000 h Rated : 98 %
LSF 6000 h Rated : 96 %
LSF 8000 h Rated : 94 %
LSF 12000 h Rated : 80 %
LSF Preheat 2000 h Rated : 99 %
LSF Preheat 4000 h Rated : 99 %
LSF Preheat 6000 h Rated : 98 %
LSF Preheat 8000 h Rated : 97 %
LSF Preheat 16000 h Rated : 82 %
LSF Preheat 20000 h Rated : 50 %
Flux measurement reference : Sphere

Light Technical

Color Code : 827 [ CCT of 2700K] / 830 [ CCT of 3,000 K] / 840 [ CCT of 4,000 K] / 865 [ CCT of 6,500 K]
Luminous Flux (Nom) : 2850 lm
Luminous Flux (Rated) (Nom) : 2900 lm / 2900 lm /2900 lm / 2880 lm
Color Designation : Incandescent White / Warm white (WW) / Cool White (CW) / Cool Daylight
Chromaticity Coordinate X (Nom) : 0.463 / 0.44 / 0.38 / 0.313
Chromaticity Coordinate Y (Nom) : 0.42 / 0.403 / 0.38 / 0.337
Correlated Color Temperature (Nom) : 2700 K / 3000 K / 4000 K / 6500 K
Luminous E€cacy (rated) (Nom) : 81 lm/W / 81 lm/W / 81 lm/W / 80 lm/W
Color Rendering Index (Nom) : 82 / 82 / 80 / 80
LLMF 2000 h Rated : 94 % / 94 % /94 % /93 %
LLMF 4000 h Rated : 93 % / 93 % / 93 % / 91 %
LLMF 6000 h Rated : 92 % / 92 % / 92 % / 90 %
LLMF 8000 h Rated : 91 % / 91 % / 91 % / 89 %
LLMF 12000 h Rated : 90 % / 90 % / 90 % / 87 %
LLMF 16000 h Rated : 90 % / 90 % / 90 % / 88 %
LLMF 20000 h Rated : 90 % / 90 % / 90 % / 87 %

Operating and electrical

Power (Rated) (Nom) : 36.3 W
Lamp current (nom.) : 0.435 A

Temperature

Design temperature (nom.) : 30 °C

Control and dimming

Dimmable : Yes

Mechanical and housing

Cap-base infrormation : 4P

Approval and application

Energy Efficiency Class : G
Mercury (Hg) content (max.) : 2 mg
Mercury (Hg) content (nom.) : 2.0 mg
Energy consumption kWh/1,000 hours : 37 kWh ,
Registration Number : 423269 / 423270 / 423271 / -

Product Data

Full product code : 871150070673740 / 871150070674440 / 871150070675140 / 871150063520440
Order product name : MASTER PL-L 36W/827/4P 1CT/25 / MASTER PL-L 36W/830/4P 1CT/25 / MASTER PL-L 36W/840/4P 1CT/25 / MASTER PL-L 36W/865/4P 1CT/25
EAN/UPC - Product : 8711500706737 / 8711500706744 / 8711500706751 / 8711500635204
Order code : 927903408270 / 927903408370 / 927903408470 / 927903486570
Numerator - Quantity Per Pack : 1
Numerator - Packs per outer box : 25
Material Nr. (12NC) : 927903408270 / 927903408370 / 927903408470 / 927903486570
Net Weight (Piece) : 104.000 g
ILCOS Code : FSD-36/27/1B-E-2G11 / FSD-36/30/1B-E-2G11 / FSD-36/40/1B-E-2G11 / FSD-36/65/1B-E-2G11
