Visual Inspection Digital Microscope (Large Viewing Field)
Brand: Rankconn Instruments
Model: RC-101D
Technical Specification:
| Model | RC-101D |
| Zoom ration | 1 to 14 X |
| Working Distance | 10cm and above |
| Pixel Resolution | 1920 x 1080 |
| Display Resolution |
HDMI: 1080P @ 60fps LAN port: 1080P @50fps |
| Focus method | Auto focus/Manual focus (Both Features) |
| Output | HDMI |
| Control Setting Features |
Monitor on screen display control setting (Wireless Mouse control ) |
| Camera Image Sensor | 1/2.8 Color CMOS |
| Whiteness | Auto/Manual |
| Power | DC 12V |
| Zoom | Viewing Field (L x W) |
| 1X | 171 x 92 mm |
| 2X | 89 x 50 mm |
| 3X | 71 x 40 mm |
| 4X | 60 x 33 mm |
| 5X | 52 x 29 mm |
| 14X | 24.3 x 13.5 mm (A4 Size) |
