| Model |
SUPER -120S-7 |
SUPER -120S-12 |
SUPER -300S-5 |
SUPER -300S-7 |
SUPER -300S-12 |
MD-165 -150S-30 |
MD -165S-30 |
PHS -320S-7 |
PHS -320S-12 |
|
|
Capacity (kg) |
Paddy 560g/liter |
2800~12000 | 4000~30000 |
Maize (690/liter) 7000~15000 |
Maize (690/liter) 7000~16500 |
7800~32000 | ||||
|
Wheat 680g/liter |
3400~14550 | 5000~36400 | 9600~38800 | |||||||
| Dimension (mm) | Length | 3971 | 4321 | 4302 | 4395 | 4745 | 5066 | 5497 | 5846 | |
| Width | 2660 | 3786 | 2810 | 4871 | ||||||
| Height | 9602 | 11629 | 9661 | 10272 | 13410 | |||||
| Net weight(kg) approx | 2453 | 2558 | 5210 | 5265 | 5420 | 3505 | 3600 | 6465 | 6530 | |
| Electricity | 3P, 220V/380V/415V/440V, 50/60Hz | |||||||||
|
Power Consumption (kW) |
6.25 | 13.1 | 11 | 13.1 | ||||||
|
Function (min) approx |
Loading | Paddy 60 | Paddy 65 | Maize 69 | Maize 75 | Paddy 55 | ||||
| Discharging | Paddy 58 | Paddy 70 | Maize 63 | Maize 70 | Paddy 50 | |||||
| Drying Rate | Paddy 0.5~1.5 %/hr |
Maize 2.5~3.5 %/hr |
Maize 1.8~2.6 %/hr |
Paddy 0.5~1.5 %/hr | ||||||
|
Temp. increase range Ambient Temp. |
+26~50℃ | +16~76℃ | +25~42℃ | +41~71℃ | +21~86℃ | +46~80℃ | +15~45℃ | +15~70℃ | ||
| Applicable region | Regular | Cold‧Frigid | Regular | Cold | Frigid | Regular‧Cold‧Frigid | Regular | Cold | ||
| Applicable grains | Paddy, Wheat | Paddy, Wheat, Maize | Paddy, Wheat | Paddy, Wheat, Maize | Maize |
Paddy, Wheat |
Paddy, Wheat, Maize | |||
| Boiler capacity ton/hr | 0.6 | 0.8 | 1.0 | 1.8 | 2.2 | 1.2 | 1.2 | 2.4 | ||
| Boiler pressure | 7 kg/c㎡ | |||||||||
| Safety Devices | Thermo-over relay, Air pressure switch, Full load buzzer, Timer, Control fuse |
Thermo-over relay, Air pressure switch, Full load buzzer, Timer, Control fuse, Rotary valve sensor |
||||||||
|
※Drying rate list is for reference only. Actual data will differ by ambient temperature, relative humidity, grain variety, hot air temperature, moisture rate before and after drying.
※The specification and graph is for reference only. Actual specification of SUNCUE product shall be based on the Sales Confirmation which customers sign and delivered products. ※Specification subject to change without notice. |
||||||||||
