Dosing Mode | Double lines dual filler filling with online weighing |
Filling Weight | 100-2000g |
Container Size | ф60-135mm; H 60-260mm |
Filling Accuracy | 100-500g, ≤±1g; ≥500g, ≤±2g |
Filling Speed | Above 100 cans/min(#502), Above 120 cans/min(#300~#401) |
Power Supply | 3P AC208-415V 50/60Hz |
Total Power | 5.1 kw |
Total Weight | 650kg |
Air Supply | 6kg/cm 0.3cbm/min |
Overall Dimension | 2920x1400x2330mm |
Hopper Volume | 85L(Main) 45L(Assist) |
