Description
• Extremely powerful jigsaw with VTC-Electronics for fast cuts into softwood of up to 140 mm
• High sawing performance in excess of 40 meters in chipboard (19 mm) with only one battery pack charge
• Extermely handy due to small handle size and soft-grip surface
• Precise and material-matched sawing due to the viriable stroke rate, pendulum stroke and low-lying saw balde guidance with spring support
• Metabo ''Quick '' for changing saw blades without tools and with automatic ejection
• Convenient automatic start-up with automatic stroke rate acceleration
• Simple bevel cuts thanks to footplate with rest points that can be adjusted without tools
• Slectable shaving blower function ensures free view of cutting line
• Integrated LED work light for illumination of the cutting line
• Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised stroke rates, which remain constant under load
• Restert protection: prevents unintentional start-up after battery pack change
• Long service life thanks to optimum gear and motor design and robust die-cast aluminum gear housing
Technical Specifications
| Model | STA 18 LTX 140 |
| Type of battery pack | LiHD |
| Battery voltage | 18 V |
| Cutting depth wood | 140 mm/ 5 1/2'' |
| Cutting depth NF metal | 35 mm/ 1 3/8'' |
| Cutting depth sheet steel | 10 mm/ 3/8'' |
| Swivel range from/ to: | - 45 / + 45 |
| Pendulum stroke levels | 4 |
| Strokes in idle | 1000 - 3000 rpm |
| Saw blade stroke | 26 mm/ 1 1/32'' |
| Weight without battery pack | 2.3 kg/ 5.1 lbs |
| Weight with battery pack | 2.7 kg/ 6 lbs |
| Vibration | |
| Sawing wood | 12 m/s |
| Uncertainty of measurement K | 1.8 m/s |
| Sawing metal | 12 m/s |
| Uncertainty of measurement K | 1.8 m/s |
| Noise emission | |
| Sound pressure level | 98 dB(A) |
| Sound power level (LwA) | 101 dB(A) |
| Uncertainty of measurement K | 3 dB(A) |
