Description
SPECIFICATIONS
Automotive No
PPAP No
Type Dry
Contact Arrangement SPST-NO
DC Coil Voltage (V) 5
Coil Current (mA) 10
Coil Resistance (Ohm) 500
Maximum Contact Resistance (MOhm) 150
Insulation Resistance (Ohm) 5T(Min)
Maximum Pick-Up Voltage 3.5VDC
Maximum AC Switching Voltage (V) 200
Maximum DC Switching Voltage (V) 200
Maximum Switching Current (A) 0.5
Minimum Dropout Voltage 0.75VDC
Maximum Carry Current (A) 1
Isolation Across Contacts 500VDC(Min)
Isolation Across Coil and Contacts 1.5KVDC(Min)
Maximum Switching Power 10W
Operate Time (ms) 0.5
Release Time (ms) 0.1
LED Indicator No
Push to Test Button No
Coil Suppression Diode No
Mounting Through Hole
Termination Style PC Pin
Number of Terminals 8
Relay Construction Non-Latching
Minimum Operating Temperature (°C) -20
Maximum Operating Temperature (°C) 70
