STD ACCES. (13M DRILL CHUCK, OIL CAN & WRENCH SET)OPTIONAL STAND # 10240B

**INDENT BASIS: 45 TO 60 DAYS SUBJECT TO T&C.
FEATURES:
• Two electronically controlled speed ranges
• Well-made mill/drill for small workshop use
• Dual downfeed controls
• Coarse for drilling,Fine for milling
• Rigid rectangular column with dovetail guides for head

SPECS:
Drilling capacity 25 mm
End mill capacity 16 mm
Face mill capacity 50 mm
Longitudinal axis (X) 400 mm
Cross axis (Y) 145 mm
Headstock travel (Z) 300 mm
hroat 230 mm Max. distance spindle to table 380 mm
Spindle taper MT3 or R8
Spindle speed :
High range 100-2000 ±10% rpm (variable speed)
Low range 100-1000 ±10% rpm
Table effective sive 550x160 mm
T-slot size 12 mm
Motor output power 600 W
Overall dimension (LxWxH) 720x760x990 mm
Packing size (LxWxH) 780x800x1050 mm
Weight (Net/Gross) 165/198 kg
