Positive Displacement Pumps
HDB3 & HDB4 Metallic 3" & 4" (80 mm & 100 mm) AODD  Heavy-Duty Ball Valve Pumps
HDB3 & HDB4 Metallic 3" & 4" (80 mm & 100 mm) AODD  Heavy-Duty Ball Valve Pumps

 2

HDB3 & HDB4 Metallic 3" & 4" (80 mm & 100 mm) AODD  Heavy-Duty Ball Valve Pumps

ABS Engineering & Trading Sdn Bhd flag
Danh mục: Positive Displacement Pumps Có sẵn
Có thể mua trên trang web chính thức
Để biết thêm thông tin, truy cập trang web chính thức của chúng tôi tại absfluidsolution.com
Truy cập Trang web Chính thức Liên hệ với chúng tôi
Specifications
  • Porting Size: 3" 150# ANSI Flange 4" 150# ANSI Flange
  • Capacity: 0 - 300 gpm (1136 lpm)
  • Air Distribution Valve: No-lube, no-stall design
  • Solids Handling: Up to 0.875" (22.2mm)
  • Heads up to: 125 psi or 289 ft. of water (98.6 bar or 88 meters)
  • Stroke: 2.0 gallons (7.6 litres)
  • Max Operating Pressure: 125 psi (8.6 bar)
  • Weight: Cast Iron 460 lbs (207 kg) Stainless Steel 480 lbs (216 kg)
Mô tả

Heavy-duty HDB3 and HDB4 Metallic AODD Ball Valve Pumps in 3-inch and 4-inch sizes, suitable for demanding industrial fluid transfer applications.HDB3 & HDB4 METALLIC 3" & 4"(80mm & 100mm) AODD - HEAVY-DUTY BALL VALVE PUMPS

The SANDPIPER HDB3 METALLIC 3" (80 MM) and HDB4 METALLIC 4" (100 MM) set a high standard for handling thin, highly viscous fluids and small solids. With industry-leading maximum flow rates up to 300 gpm, these pumps offer exceptional durability and suction capabilities for challenging environments, outperforming standard pumps in harsh ball valve applications.





Features



Applications
  • Top-port option: Suitable for fluids with floating or suspended solids and gases, minimizing material buildup and easing evacuation.
  • Down-Port option: Optimal for settling solids, directing discharge below the pump center to reduce diaphragm wear and extended pump life
  • Extended-Wear Components: Reinforced with robust bushings, weighted check valve balls, and wear-resistant diaphragm pads for longevity.

  • Abrasive Slurry Handling: Built for high-abrasion environments with extended-wear features.
  • Solids-Laden Fluid Transfer: Specialized porting configurations address fluid and solid separation challenges
  • Oil & Gas, Chemical, and Industrial processing: Reliable under extreme conditions and compliant with rigorous standards.

Why Choose SANDPIPER HEAVY DUTY BALL VALVE PUMPS

Exclusive ESADS+ System: SANDPIPER’s ESADS+ ensures rapid maintenance, reducing downtime by up to 90%.

Extended Durability for Critical Applications: Thicker castings, wear pads, and specialized bushings maximize resistance to wear.

Engineering Evolution for Superior Performance: Optimized through advanced engineering balancing durability and efficiency.
      Heavy-duty HDB3 and HDB4 Metallic AODD Ball Valve Pumps in 3-inch and 4-inch sizes, suitable for demanding industrial fluid transfer applications.



FOR MORE INFORMATION, KINDLY CLICK HERE:
HDB3 & HDB4 Metallic 3" & 4" (80 mm & 100 mm) AODD – Heavy-Duty Ball Valve Pumps
