Cyclic salt spray corrosion chamber exposes sample to a series of different environments in repetitive cycles that incorporate temperature, humidity and salt spray. Accelerated corrosion test methods included ASTM B117, ASTM G85, ISO9227, IEC60068-2-52, ISO7253 and many others.
CCT chambers are upgraded to programmable controller and Ethernet access. All models are automated, and can working continuously. various models can meet different test requirements.
| Model | SC-010 | SC-016 | SC-020 | ||
| Internal dimensions (mm) | 770*1430*700 | 800*1900*850 | 850*2250*850 | ||
| Overall dimensions (mm) | 1450*2520*1620 | 1350*3000*1700 | 1650*3200*1700 | ||
| Temperature range | 10℃～90℃ | ||||
| Humidity range | 30% ~ 98% RH | ||||
| Temperature tolerance | +/- 2.0 ℃ | ||||
| Humidity tolerance | +2%，-3% | ||||
| Salt concentration tolerance | ±1% | ||||
| Spray deposition | 1～2ml / 80cm2 · h | ||||
| Temperature Controller | Programmable color display touch screen controller& Interface R232& PC Link | ||||
| Temperature sensor | Platinum resistance. PT100Ω / MV A-class | ||||
| Humidity sensor | dry and wet bulb sensor | ||||
| Interior /Exterior material | Glass fiber reinforced plastics; (corrosion resistance, Anti-aging, high strength) | ||||
| Power Supply | 380V 50HZ Three-phase five little system | ||||
| Test standard | IEC60068-2-52, IEC61701-2， ASTM G85，ISO 7253 | ||||
